1000m Night Vision IP Laser Night Vision Camera

Model NO. SH-HLV1020 Sensor CMOS HDMI Format 1080P Horizontal Resolution 600tvl Kind Autofocus Lens Certification CE, FCC, ISO9001: 2000 Feature Waterproof / Weatherproof Effective Distance Maximum 1km at Night, Maximum 2km in The Day Sensor Size 1/1.8′′ Remote Control With Remote Control Maximum Night Vision Distance 1km Maximum Daytime Vision Distance 2km Pixel 2.1 Mega Pixel Focal Length 10-320mm International Protection IP66 Weight 25kg Transport Package Carton / Wooden Case Specification CE FCC Trademark CZVZ Origin Shandong Province, China Production Capacity 1000 Units / Month

Packaging & Delivery

Package Size 65.00cm * 58.00cm * 38.00cm Package Gross Weight 28.000kg

Product Description

1  Product features     -Adopt laser illuminating system, long lighting distance with large scope, uneasy  to be discovered;   -Day & Night low illumination megapixels color to black camera, realize  continuous monitoring day and night;   -Auto exposal control, AWB, AGC;   -High-efficiency video processing chips, H.264 code, HD images  of millions resolution;   -Dual-stream function to meet the different network broadband;   -Rich network protocol, good adaptability;   -Mobile surveillance and alarm linkage, intelligence video monitoring;   -Built-in Web Server, convenient to control;   -Shifting pan-tilt, realize all directions no blind spot monitoring and high accurate  orientation;   -Smart shell with professional design, light, firm, anti-corrosion,  waterproof and acid rain proof.     2 Technical indicators   Effecting  Distance 1000m at night, 2000m in daytime Imaging  Lens Focal length: 10-320mm, 22x infrared correction high definition lens FOV: 1.2°-36.8° Imaging  Components Sensor: 1/1.8'' Progressive Scan CMOS Pixel: 1.3 MEGA Low illumination: 0.1 LUX (color), 0.01LUX (black&white) Video  Code Format: H.264 Video resolution: 1280x960 (12.5fps), 1280x720(25fps),  support dual-stream  Title on screen display: logo, date, time, alarm Image adjustment: brightness, contrast, saturation HK series support Hikvision platform Network  Protocol TCP/IP, ARP, ICMP, FTP, RTP/RTCP, NTP, DNS,  DDNS, SNMP,  PPPoE, RTSP Pan-tilt Upload: 20kg Angle: pan 360°, tilt is optional Pan speed: 0.1°~9°/s, Tilt speed: 0.1°~4°/s Pre-setting bits: 255 8 tracking paths Illuminator Wave length: 810nm infrared laser illuminator Lighting angle: 0.5°~17° Interface Network interface: 1×10 Base-T/100 Base-TX, RJ45 interface Power supply interface: AC24V±10%, 5A Environment Indicators Working temperature: -25°~+55° Storage temperature: -40°~+65° Anti-saltfog: 48 hours spraying continuously under  PH 6.5~7.2 Protection level: IP66 Relative humidity: 90% Lightning proof: 2000V Application mobile surveillance, alarm linkage, real-time clock, support manual capture and record, support  pre-setting  points, built-in WEB browser, can be connected to NVR to realize  unified  configuration and management     3 Main use   -Oil fields, Railways, Airports, harbors, engineering constructions, forests fireproofing and reconnaissance, Large areas/ invisible real-time monitoring   -Frontier and coast defense, national defense, Night campaign, facilities, department and station
